PM02.EX-1-2 Intrinsically Safe Power Supply Intended for Ex Scale
- PM01.EX-1 Intrinsically Safe Power Supply Intended for Ex Scale
- PM01.EX-2 Intrinsically Safe Power Supply Intended for Ex Scale
- PM02.EX-1-2 Intrinsically Safe Power Supply Intended for Ex Scale
- PM02.EX-2-2 Intrinsically Safe Power Supply Intended for Ex Scale
- SYS-1544-2415-T3-HRP Power Adapter
- ZR-04/1 Powerbank
- ZR-04/2 Powerbank
- ZR-04/1, ZR-04/2 Powerbank (battery)
Pcs.
Add to basket
We are near you.
We have been manufacturing weighing devices since 1984.
RADWAG UK Limited
16 Macon Court, Herald Drive, Crewe, CW1 6EA
+44 01625 569569
Delivery only on the territory of United Kingdom
We have been manufacturing weighing devices since 1984.
RADWAG UK Limited
16 Macon Court, Herald Drive, Crewe, CW1 6EA
+44 01625 569569
Delivery only on the territory of United Kingdom
Optional paid installation and training service available - please contact us for details and pricing.
Datasheet - PM02.EX-1-2 Intrinsically Safe Power Supply Intended for Ex ScaleCode:
WX-004-0257
2 years warranty
CE
Datasheet
Cable length
3 m
Protection class
IP 66 / 68
ATEX Certification
II 2G Ex eb mb [ib] IIC T4 Gb
II 2D Ex tb [ib] IIIC T70°C Db
II 2D Ex tb [ib] IIIC T70°C Db
Working in zones
1, 2 (gases); 21, 22 (dusts)
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
15 W
Operating temperature
-20 – +40 °C
Storage temperature
-20 – +60 °C
Relative humidity
10% – 85% RH no condensation
Housing
Stainless steel
Device dimensions W x D x H
216×174×64 mm
Overview
PM02.EX-1-2 Intrinsically Safe Power Supply Intended for Ex Scale
The certified intrinsically safe PM02.EX power supply, manufactured by RADWAG, has been designed to power the HRP.EX.
PM02.EX power supply comes in two designs:
-
PM02.EX-1-2: power supply intended for operation in hazardous area:
- Zone 1 and 2, where there is a risk of explosion due to mixture of air with vapour, mist or gas, classified as explosion group IIC, IIB and IIA and as temperature class T1, T2, T3, T4.
-
Zone 21 and 22, where there is a risk of explosion due to mixture of air with dust, flammable fibres and volatile fuels, classified as explosion group IIIC, IIIB and IIIA.
-
PM02.EX-2-2: power supply intended for operation outside hazardous area, equipped with intrinsically safe circuits that can be placed in:
- Zone 1 and 2, where there is a risk of explosion due to mixture of air with vapour, mist or gas, classified as explosion group IIC, IIB and IIA and as temperature class T1, T2, T3, T4.
- Zone 21 and 22, where there is a risk of explosion due to mixture of air with dust, flammable fibres and volatile fuels, classified as explosion group IIIC, IIIB and IIIA.
The certified intrinsically safe PM01.EX power supply, manufactured by RADWAG, has been designed to power the HX5.EX indicator.
PM01.EX power supply comes in two designs:
-
PM01.EX-1: power supply intended for operation in hazardous area:
- Zone 1 and 2, where there is a risk of explosion due to mixture of air with vapour, mist or gas, classified as explosion group IIC, IIB and IIA and as temperature class T1, T2, T3, T4.
-
Zone 21 and 22, where there is a risk of explosion due to mixture of air with dust, flammable fibres and volatile fuels, classified as explosion group IIIC, IIIB and IIIA.
-
PM01.EX-2: power supply intended for operation outside hazardous area, equipped with intrinsically safe circuits that can be placed in:
- Zone 1 and 2, where there is a risk of explosion due to mixture of air with vapour, mist or gas, classified as explosion group IIC, IIB and IIA and as temperature class T1, T2, T3, T4.
- Zone 21 and 22, where there is a risk of explosion due to mixture of air with dust, flammable fibres and volatile fuels, classified as explosion group IIIC, IIIB and IIIA.
